Equipment

To achieve our research goals, our facilities support high-accuracy RF capabilities, including advanced vector signal generation and high-performance vector network analysis. These systems enable us to conduct thorough investigations into the electrical and RF properties of devices and systems across a wide frequency range. The laboratory is equipped with a variety of instruments, a selection of which is listed below:


Network, Spectrum, & Signal Analyzers


Rohde & Schwarz ZNA67

R&S Vector Network Analyzer
(10 MHz - 67 GHz)

Keysight EXA N9010A

Keysight Signal Analyzer
(10 Hz - 7 GHz)

Agilent ESA E4407B

Agilent Spectrum Analyzer
(9 KHz - 26.5 GHz)

Keysight PNA N5221A

Keysight PNA Network Analyzer
(900 Hz / 10 MHz - 13.5 GHz)

Rigol DSA1030

Rigol Spectrum Analyzer
(9 kHz - 3 GHz)

GW Instek GSP-810

GW Instek Spectrum Analyser
(150 kHz - 1 GHz)

Electromagnetic Field (EMF) Measurements


NARDA SRM-3006

Frequency-Selective EMF Measurement up to 29.5 GHz

NARDA NBM-500

FieldMan-Electromagnetic Field Meter from 0 Hz (DC) to 90 GHz

NARDA EF9091

E-Field Probe for NBM-500 (100 MHz - 90 GHz)

Software-Defined Radio (SDR)


Ettus USRP X310

Ettus Research Universal Software Radio Peripheral (USRP)

Ettus USRP N210

Ettus Research Universal Software Radio Peripheral (USRP)

Developer Kits (DK)


Anokiwave AWMF-0221

24-30 GHz Dual Pol Quad 4x2 Beamformer IC

Anokiwave AWMF-0224

Dual Channel IF Transceiver IC (24.25-29.5 GHz operation)

Oscilloscopes


Agilent DS03062A

60 MHz, 2-Channel Oscilloscope

Keysight DSO-X2002A

70 MHz, 2 Analog Channels

GW Instek GOS-620

20 MHz Dual Trace Oscilloscope

EZ GOLDSTAR OS-5020

20 MHz Analog Oscilloscope

Signal Generators


Keysight N5182B MXG

RF Vector Signal Generator
(9 kHz - 6 GHz)

Keysight N5183B MXG

Microwave Analog Signal Generator
(9 kHz - 40 GHz)

Rigol DG1022A

Arbitary Waveform Generator
(0.1μHz - 20 MHz)

Aim-TTi TGA 1241

True Arbitrary Waveform Generator
(0.1mHz - 16 MHz)

GW Instek GFG-8250A

Analog Function Generator
(0.5 Hz - 5 MHz)

Antennas


ETS-Lindgren 3116

Double-Ridged Guide Waveguide Horn Antenna (18 GHz - 40 GHz)

ETS-Lindgren 3117

Double-Ridged Guide Waveguide Horn Antenna (1 GHz - 18 GHz)

Aaronia HyperLOG 60180

Log-Periodic Dipole Antenna (LPDA)
(680 MHz - 18 GHz)

Netgear ANT2409

Indoor/Outdoor 9 dBi Omni-Directional Antenna
(2.4 GHz - 2.485 GHz)

Unmanned Aerial System/Vehicle (UAS/UAV)


Ucandrone OCTOPUS

Octocopter (8 Rotors) UAV
MTOW 15 Kg / Max Payload 4 Kg

Tools & More


Shapeoko CNC Router

Carbide (3D) Compact Router

DeWalt D26200 Router

900W 8mm (1/4") Fixed Base Router

LPKF ProtoFlow S4

SMD soldering compact reflow oven

Mega Electronics PA310

PCB etch tank (320x260mm boards)

Proma 140002

UV Exposure Unit with Vacuum 260W

Konus 5424

Powerful Stereoscopic Zoom (7-45x)

Hakko FX-951

Digital Soldering Station (24V-70W)

Yaesu G-5500

Az / El Antenna Rotator System

Yaesu GS-232B

Rotor Computer Interface

Mean Well TS-1500-212B

Pure Sine 1500W/12V DC/AC Inverter

Throwdown Dummy

30kg Humanoid Wrestling Dummy

NOVA PA250D

Crane with 125/250 Kg Lift Capacity

FGK-320 Laminator

A3-A4 Laminator

Power Supply


Extech 382270

Quad Output DC (0-30V/0-5A)

Keysight E3630A

Triple Output (6V, 2.5A / 0-±20V, 0.5A

Digital Multimeter


Keysight 34450A

High Accuracy Digital Multimeter

Extech MP530A MultiPro

True RMS Professional Multimeter

Evaluation/Development Boards/Kits (DSP/FPGA)


Texas Instruments C64x

PCI DSP Imaging Evaluation Kit C64x

Humatics P442

Wireless Development Kit

Software


MathWorks MATLAB

Multi-Paradigm Programming Lang.

SIMULIA CST Studio Suite

3D EM Analysis Software

Remcom Wireless InSite

3D Wireless Prediction Software
